Features
| Wide range of AC input voltage 90-264VAC |
| Protections against: short circuit/over current/over voltage/ |
| Satisfies 1KV Surge immunity level and can be compatible with 4KV ligtning strike requirements. |
| Meets energy star level V |
Electrial Specifications
| Input Voltage Range | 90-264VAC | Operation Temperature | -5~40℃ | ||||||||
| Input Current | 400mA | Storage Temperature | -40~70℃ | ||||||||
| Average Efficiency | Meets energy star level V | Humidity | 5% to 90% non condenising | ||||||||
| Output Voltage Range | ±5% | MTBF | 100,000 hours at full load at 25℃ ambient, calculated per MIL-HDBK-217 | ||||||||
| Standby Power | 0.3W Max | ||||||||||
| Safety Standard | CCC(GB4943.1) | ||||||||||
| Weight | 73g | Dimensions | 62.0mm (L) ;29.0mm (W) ;40.0mm (H) | ||||||||
| Applications | ITE Equipment | ||||||||||
Output data
Model | Voltage（V） | Current（A） | Ripple |
| Av.Eff.（%）Min |
UE10LC-050YYYSPA | 5.0 | 0.01-2.0 | 200 | Y Y | 73.37 |
